135kVA 108KV AC High Voltage Resonant Test System for 35KV Cables Transformer

This series devices are designed for AC withstand voltage test of substation primary equipment under 550KV or below, mainly composed of variable-frequency power supply, exciting transformer, reactor and capacitive Voltage divider

Features:

1. rated voltage:
27kV--- meets AC withstand voltage test of 10kV cable

working frequency 30-300Hz

Test voltage is not more than 22kV, test time is 5min;
54kV--- meets AC withstand voltage test of 35kV cable

Working frequency 30-300Hz

Test voltage is not more than 52kV, the test time is 60min;

81kV--- meets AC withstand voltage test of 10kV cable

working frequency 30-300Hz

Test voltage is not more than 22kV, test time is 5min;
54kV--- meets AC withstand voltage test of 10kV substation

Working frequency 30-300Hz

Test voltage is not more than 28kV, test time is 1 min;

108kV--- meets AC withstand voltage test of 35kV sbustation

Working frequency 30-300Hz

Test voltage is not more than 100kV test time is 1 min;

2. output voltage waveform distortion rate: <1.0%
3. allow continuous working hours: one time working for 60 minutes under rated conditions;
4. Quality factor of the device: Q > 30 (f=45Hz)
5. device output waveform: sine wave
6. input power supply: three phase 380V
7. frequency regulation range: 30Hz ~ 300Hz
8. system measurement precision: 1.5%
9. over voltage, over current, zero start and other protection functions.

COMPOSITION

1. Frequency conversion power supply

(1) rated power: 7 kW
(2) Input voltage: three phase 380V 50Hz
(3) output voltage: 0 ~ 400V adjustable
(4) Output voltage frequency: 30 ~ 300Hz
(5) 0.1Hz regulation step
(6) Frequency instability is less than 0.02%
(7) Output current: 0 ~ 18.75A

2. High voltage reactor (4 units)

(1) rated working voltage: 27kV
(2) rated working current: 1.25A
(3) rated inductance: 100H
(4) Continuous working time: 60min
(5) Temperature rise: less than 65ºc
(6) Working frequency: 30~300Hz

3. excitation transformer

(1) rated capacity: 7.5kVA
(2) input voltage: 400V
(3) output voltage: 1.5/3/6kV
(4) output current: 5/2.5/1.25A

4. capacitance divider (1 units)

(1) self capacitance: 800pF
(2) rated voltage: 110kV
(3) working frequency: 30 ~ 300Hz
(4) uncertainty: 1.5%
(5) Rated voltage: 110kV/800pF

5. test line (1 sets)
