    Switch Type Three Phase Unbalanced Device Intelligent Automatic

    ZXPH330 Three-Phase Unbalanced Device


    Product Description

    Introduction

    The ZXPH330 commutation switch type three-phase imbalance control device is a real-time and intelligent automatic load regulation system that performs on load commutation scheduling for single-phase loads, effectively solving the problem of three-phase imbalance in low-voltage distribution networks.


    Technical indicators:

    Parameter namePhase changer ZXPH330-PEXmain control ZXPH330-BMC
    Commutation time0 ms
    Commutation modeon-load equal voltage 0 ms seamless commutation
    Commutation lifemore than 150,000 times
    Communication mode230MHz short-distance wireless communication230MHz short-distance wireless communication; GPRS; 485
    Communication distance≤4000m without obstacles, ≤1500m between buildings≤4000m without obstacles, ≤1500m between buildings
    Connection modethree-phase four-wire systemthree-phase four-wire system
    Interlock modehardware differential pressure, signal differential interlock;Software check block
    Adjustment modereal-time dynamic current balance, Power balance Real-time dynamic current balance, power balance
    Rated voltage380V/220V380V/220V
    Rated current60A/120A (optional)0.1A; CT: 5A
    Rated frequency50Hz, allowable deviation±5% 50Hz, allowable deviation: ±5%
    Insulation resistance≥100MΩ≥100MΩ
    Overload capacity2 times rated current: 1 minute2 times rated current: 1 minute
    Withstand voltagepower frequency 2.5kV, impact 5kVpower frequency 2.5kV, impact 5kV
    Power consumption≤2.5W≤2.5W
    Installationpole/wall hangingpole/wall hanging
    Use environmentindoor/outdoor, -40℃~85℃indoor/outdoor, -40℃~85℃
    Altitude≤4000 m≤4000 m
    Weight1560g1590g
    Dimensions286mm*174mm*87mm228mm*160mm*80mm


    Packaging & Shipping
