    Multifunctional Portable Intelligent Battery Activator Maintenance Activation Instrument

    Ask Lasest Price
    Brand Name : GDZX
    Model Number : ZX-3932
    Certification : ISO9001
    Price : 2300 USD/set
    Supply Ability : 100 Piece/Pieces per Month
    Delivery Time : 7
    • Product Details
    • Company Profile

    Multifunctional Portable Intelligent Battery Activator Maintenance Activation Instrument

    Multifunctional Portable Intelligent Battery Activator Maintenance Activation Instrument



    Product Introduction :

    The device is multifunctional testing device for storage battery maintenance. .

    It has independent functions of battery charge, discharge, activation, internal resistance test, performance test.

    All the charging and discharging are programmable controlled. It auto stop in case of overheating

    The tester can maintain cell (2V, 6V, 12V..) on-line or off-line


    Main characteristics:
    • Full functions for routine maintenance


    • small volume, convenient for moving


    • Temperature monitoring, exhaust fan will be switched on automatically when the temperature is over preset value


    • Three phase charging method can avoid over charge


    • Voltage limiting protection


    • Module design, convenient for maintenance


    • Friendly user interface, large screen LCD

    Technical indicators:

    ItemModeResolutionAccuracy
    Charging current1~100A( 2V mode) 0.01A0.20%
    1~60A(6V mode)
    1~30A ( 12V mode)
    Discharging current1~100A( 2V mode) 0.01A0.20%
    1~60A(6V mode)
    1~30A ( 12V mode)
    Total charge/discharge voltage1.7V~2.6V(2V mode)0.001V (2V mode) 0.01V(6V, 12V mode)≤0.2%
    5.1V~7.2V(6V mode)
    10.2~15V (12V mode)
    Temperature Measuring range-18~300.0010.1
    Power supplyAC220V±10%
    Dimension300*425*200mm
    Weight15KG
    Working environment0~50, 5%RH~90%RH in Room
    Display480*800 LCD
    Communication interfaceRS232 & USB (can be customized)
    Carrying wayPortable
    Heat dissipation wayForced air cooling



    For more information , click this link to send us inquiry now !

    Product pictures:

    Our company :

    Wuhan GDZX Power Equipment Co.,ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China.
    What's more, our customers come from different countries like America, England, Peru , Malysia, Vietnam ,Singapore and so on.

    Our main products are High voltage tester , Cable Fault Locator, Power Quality Analyzer, Standard Power source , Testing Transformer and so on.
