Product introduction:
Transformer Winding Testing Equipment Short-Circuit Impedance
Tester
Low-Voltage Short-Circuit Impedance Test Is To The Most Direct Way
To Check The Deformation Of The Winding After Transformer Suffered
From Short-Circuit Current Or Mechanical Collision During
Transportation And Installation, The Test Is Important To Help
Determine Whether The Transformer Can Be Put Into Operation, And
Whether Disintegration Is Necessary For Inspection. ZX-BZK
Transformer Short-Circuit Impedance Tester Comes With Adjustable
Power Output, Particularly Suitable For 110kV And Above Main
Transformer On Site Measurement.
Features
1. With switching power supply, just one time wiring connection can
finish measurement for all the windings, no matter it is single
phase transformer or three phase transformer
2. Single phase measurement mode. To three phase transformers, each
phase short circuit impedance, reactance, inductance can be
obtained automatically after three times boosting.
3. Adopts phase locking technology, synchronize sampling AC signal
which ensures accuracy
4. current, voltage and power, frequency can be measured at the
same time
5. Support external connection with CT/PT to extend measuring range
6. With memory to store data, with printer
7. LCD display with operation menu, data can be read clearly even
under direct sunlight
Technical Indicators
1. Measurement accuracy: Voltage, current 0.2% 2. Power: COSφ>0.1 0.5%; COSφ≤0.1 1.0% 3. Impedance: COSφ>0.1 0.5%; COSφ≤0.1 1.0% 4. Voltage measurement range: AC 3V-300V 5. Internal power supply output range: voltage 0-250V, current
0-10A 6. Current measuring range: AC 0.2A-20A 7. Working temperature: -10℃-50℃ 8. Humidity: 0-80% 9. Power supply: AC220V±10%,50Hz±1Hz 10. Dimension: 360×220×150mm 11. Weight: about 5kg |
